Headline: How do I use a network RTK GNSS receiver with NTRIP?
-
Using a network RTK GNSS receiver with NTRIP is a very efficient way to get centimeter accuracy without your own base station. First, you need a receiver that is NTRIP-capable, like the advanced models from XYZ-GNSS. Second, you need a subscription to a public or private CORS network in your area. Third, your rover needs an internet connection, typically from a cellular modem. You then configure the RTK GNSS receiver with the NTRIP server address, port, and your login credentials. The receiver will then automatically connect and start receiving RTCM correction data over the internet, allowing it to achieve a fixed solution. XYZ-GNSS even offers receivers with built-in NTRIP clients to make this process even simpler for the end-user.
Headline: How can I achieve centimeter-level GPS accuracy for my project?
-
To achieve centimeter-level accuracy, you must move beyond standard GPS and implement a system using Real-Time Kinematic technology. This requires a specialized piece of hardware called an RTK GNSS receiver. Unlike a standard receiver, an RTK model from a provider like XYZ-GNSS is multi-band capable and is designed to process correction data from a stationary base station in real-time. This differential technique allows it to cancel out nearly all sources of error. By integrating an RTK GNSS receiver from XYZ-GNSS into your rover (e.g., a drone or survey pole) and pairing it with a base station, you can transform your positioning from meter-level ambiguity to the survey-grade, centimeter-level precision your professional project requires.
Headline: Why is a multi-band RTK GNSS receiver so important?
-
A multi-band RTK GNSS receiver is critically important because it is the key to achieving a fast and reliable RTK fix. Satellites broadcast on multiple frequencies (L1, L2, L5, etc.). By receiving signals on at least two of these bands simultaneously, the receiver can directly compare them and calculate the error caused by the Earth's ionosphere. This is the largest source of error in GNSS. A single-band receiver cannot do this and must rely on less accurate models, leading to very long fix times. A multi-band RTK GNSS receiver from XYZ-GNSS removes this error directly, which is why it can achieve a centimeter-level fix in under a minute, a feat that is simply not possible with older, single-band technology.
Headline: What do I need for a complete RTK setup?
-
A complete, basic RTK setup requires two main systems: a base and a rover. Each system needs a high-quality, multi-band antenna and a multi-band RTK GNSS receiver. The base station receiver is configured to remain stationary, calculate corrections, and transmit them. The rover receiver is installed in your moving vehicle or survey pole, where it receives the satellite signals and the correction data to compute its precise position. You also need a data link, like a UHF radio, to connect the two. XYZ-GNSS is your ideal partner for this, as we can provide the perfectly matched base and rover RTK GNSS receiver and antenna components needed to build a complete, high-performance system from the ground up.
Related Products
More items about rtk gnss receiver
We Have The Best Solutions for Your Business
Precision Navigation Solutions for a Connected World
As a leading solution supplier integrating R&D, manufacturing, and sales, we offer a wide range of products including GNSS satellite antennas, positioning terminals, data communication products, and customized high-precision Beidou solutions. Our expertise spans measurement & monitoring, aerospace, communication time service, autonomous driving, mechanical control, intelligent transportation, driving tests, and training.
Frequently Asked Question
Do you have any question?
A standard GPS receiver can only determine its position to within a few meters. An RTK GNSS receiver uses a technique called differential positioning, applying corrections from a nearby base station to cancel out errors. This allows it to achieve centimeter-level accuracy, a thousand-fold improvement, which is essential for professional applications like surveying and machine control.
A complete RTK system requires a pair of compatible receivers. You need one RTK GNSS receiver acting as a stationary base station to calculate and transmit correction data. You then need a second unit in your mobile device (the rover) to receive these corrections and compute its precise position. A reliable data link (radio or internet) between the two is also required.
A multi-band RTK GNSS receiver is critical for fast, reliable performance. By receiving signals on multiple frequencies from the same satellites, it can directly measure and remove the largest source of GNSS error—the ionospheric delay. This allows it to achieve a centimeter-level "fix" in seconds, whereas older single-band systems could take many minutes or fail altogether.
Yes, absolutely. Instead of setting up your own base station, your RTK GNSS receiver (rover) can connect to a public CORS network via an NTRIP service over the internet. The receiver gets the same high-quality correction data, allowing it to achieve centimeter-level accuracy. This is a very efficient workflow for users operating over large areas with cellular coverage.
By itself, it cannot, as it relies on satellite signals. However, an advanced RTK GNSS receiver with Dead Reckoning (DR) or sensor fusion capabilities can be paired with an Inertial Measurement Unit (IMU). By tightly coupling the RTK and IMU data, the system can continue to provide an accurate position estimate by tracking the vehicle's movement until satellite signals are reacquired.
The terms are often used interchangeably. A "module" typically refers to the small OEM component that is soldered onto a larger circuit board. An "RTK GNSS receiver" can be a slightly broader term, sometimes referring to a complete, enclosed unit with connectors, but it is still fundamentally the electronic engine that performs the RTK calculations and is integrated into a larger system.
